Snapdragon 615 – processor of the middle class from the company Qualcomm, Room – MSM8939. The processor is designed for mobile devices and combines not only the processor, but also graphics accelerator.

Key Features:

The processor has 8 cores: 4 core Cortex A53 processor with a clock frequency of 1.8 GHz and 4 Cortex-A57 have a frequency of 1 GHz.
Graphics processor – Adreno 405, designed specifically for the processor Snapdragon 610/615, has a clock speed of 550 MHz and manufactured on 28 nm technology.
DSP coprocessor for processing data in real time.
Supports NFS
Supported cameras resolution 21 mega pixel.
Supports display resolutions up to 2560×1600 pixels
processor manufactured by 28nm technology.

Features Snapdragon processor 615

  • Quad-core 1.7GHz ARM Cortex A53 + quad-core 1.0GHz A53
  • 32-bit and 64-bit capable
GPU Qualcomm® Adreno™ 405 GPU
DSP Hexagon™ V50 DSP (up to 700MHz) Shared Modem & App DSP
  • Integrated 4G LTE World Mode, supporting LTE FDD, LTE TDD, WCDMA (DC-HSPA+, DC-HSUPA), CDMA1x, EV-DO Rev. B, TD- SCDMA and GSM/EDGE
  • CAT4 speeds of up to 150 Mbps
  • 3rd Generation integrated LTE modem, with support for LTE-Broadcast and LTE multimode multi-SIM (TSTS, DSDA and DSDS)
RF 3rd gen power efficient LTE multimode transceiver with Qualcomm RF360™ Front End solution for world mode bands, lower power and PCB reduction
Bluetooth BT4.0 † Integrated digital core
WiFi Qualcomm® VIVE™ 1-stream 802.11n/ac with MU-MIMO † Integrated digital core
GPS Qualcomm® IZat™ Gen8C
NFC Supported
  • 1080p60 playback with H.264 (AVC) and H.265 (HEVC) formats
  • 1080p30 capture with H.264 (AVC)
  • DASH is supported
Camera Up to 21 MP
Display Uo to WQXGA (2560×1600)
Quick Charge
  • Qualcomm® Quick Charge™ 1.0 technology, 1.5A out, Integrated Fuel Gauge
  • Qualcomm Quick Charge 2.0 technology, up to 3A out, Current Path
Memory/Storage LPDDR3 800MHz Single-channel 32-bit (6.4GBps)/eMMC 4.51 SD 3.0 (UHS-I)
Process Technology 28nm LP
QRD QRD supported
